120 m3/h New Generation Efficient Energy-Saving Vertical Sewage Pump
New generation efficient energy-saving vertical sewage pump features:
1. Pump structure is solid, dry type motor, dual mechanical seal waterproof, impeller guide flow vane, high water flow, operate indefinitely, IP68 protection.
2. The weight is light, mounted simple, and convenient maintenance.
3. Centrifugal impeller,axial flow impeller,mix flow impeller design,low head and high flow, low-energy accord with economic benefits.
4. Impeller bronze is high quality aluminum bronze material, sea water corrosion resistance and abrasion resistance,the least sand abrasion loss.
New generation efficient energy-saving vertical sewage pump applications:
1. Fish farming agricultural irrigation, low-lying areas drainage.
2. Sewage treatment and landscape waterfalls.
3. Landscape waterfalls.
4. Others: high volume water
120 m3/h New generation efficient energy-saving vertical sewage pump main standard specification performance curves:
Temperature: 0~40℃
Application: Agricultural Irrigation, fish water, river water
Impeller: 3HP,5HP:centrifugaltype7.5HP,10HP: axial flow type. 15HP,20HP: mix flow type
Seal: Dual mechanical seal
Bearing: Deep groove ball bearing
Housing: Stainless Steel
Top cover: Cast Iron
Cover: Cast lron
Impeller: Bronze
Seal housing: Cast Iron
Bearing base: Cast Iron
120 m3/h New generation efficient energy-saving vertical sewage pump technical parameters:
| Model | Power | Flow range | Head range |
| WLT type | kw | hp | m3/h | m |
| WLT-63 | 2.2 | 3 | 120 | 3 |
Other models New generation efficient energy-saving vertical sewage pump technical parameters:
| Model | Power | Flow range | Head range |
| WLT type | kw | hp | m3/h | m |
| WLT-63 | 2.2 | 3 | 120 | 3 |
| WLT-150 | 3.7 | 5 | 120 | 5 |
| WLT-200 | 5.5 | 7.5 | 210 | 4 |
| WLT-250 | 7.5 | 10 | 330 | 4 |
| WLT-300 | 11 | 15 | 420 | 5 |
| WLT-1220 | 15 | 20 | 510 | 6 |
We are a manufacturer with 30 years of production experience, and can do all kinds of large flow sewage pumps. If you need a large flow sewage pump, please contact us. Our Email is enquiry02@apkpump.com and our Whatsapp is +86 17537187726.
